9100ADAL
Sliding Door Sets
This ADA sliding door lockset meets the “no pinch and grasp” ADA requirements while offering single-action egress. Pulling the inside handle will retract the deadbolt, and then can be used to slide the door in one continuous motion.
ADA Compliant
- 2-1/2" or 2-3/4" backset standard.
- For 1-3/4" thick doors.
- Other backsets and door thicknesses available upon request (see 9100SDL for details).
- Set comes standard with 72L/1E.
- Cylinders not included.
- Most architectural finishes available.
9100ADAL-3 Entry
- 9100SDL Sliding Door Lock.
- 72L/1E-CD Outside Escutcheon with Lever.
- 72L/1E-ADA Inside Escutcheon with Lever and 7200ADA T-turn.
9100ADAL-3ST Classroom
- 9100SDL Sliding Door Lock.
- 72L/1E-CD Outside Escutcheon with Lever.
- 72L/1E-B Inside Escutcheon with Lever (blank).
9100ADAL-5 Privacy
- 9100SDL Sliding Door Lock.
- 72L/1E-ED Outside Escutcheon with Lever and Emergency Coin Release.
- 72L/1E-ADA Inside Escutcheon with Lever and 7200ADA T-turn.
9100ADAL-5i Privacy with Occupancy Indicator
- 9100SDL Sliding Door Lock.
- 72L/1E-Oi Outside Escutcheon with Lever and Emergency Release with Indicator.
- 72L/1E-ADA Inside Escutcheon with Lever and 7200ADA T-turn.
Sell Sheet
Specification Sheets
Installation Templates
Click on a swatch below to get a closer look
-
CVB
Cerakote Vortex Bronze
-
CBG
Cerakote Black Gloss
-
Cerakote White Gloss
CWG
-
CWM
Cerakote White Matte
-
CBM
Cerakote Black Matte
-
US4
Satin Brass
-
US4NL
Satin Brass + No Lacquer
-
US32D
Satin Stainless Steel
-
US26D
Satin Chrome
-
US3
Polished Brass
-
US3NL
Polished Brass + No Lacquer
-
US26
Polished Chrome
-
US32
Bright Stainless Steel
-
US9
Polished Bronze
-
US10
Satin Bronze
-
US10B
Oil Rubbed Bronze
-
US14
Polished Nickel
-
US15
Satin Nickel
-
US19
Oxidized Black + Lacquer
-
US19LL
Oxidized Black Less Lines + Lacquer
-
BN
Burnished Nickel
-
BB
Burnished Brass
-
TN
Tarnished Nickel
-
TB
Tarnished Brass
-
DURO
Duronotic
-
ESN
Electroless Nickel
-
US15A
Antique Nickel
-
US5
Satin Brass + Black
-
Cerakote
Protective Ceramic Coating
US26D
Satin Chrome
How to Specify
Function. Backset. Trim. Finish. Hand. DoorThickness.
Examples
-
ADA Sliding Door Entry Set | Standard Trim
E.g.: 9100ADAL-3. 212. 72L/1E. US26D. 134 -
ADA Sliding Door Classroom Deadlock Set | Other Lever Trim
E.g.: 9100ADAL-3ST. 212. 19L/1E. US19. 134
