9000SEC | 9100SEC
High Security Mortise Lock
The High Security Mortise Lock withstands 300x More Abuse Than the Grade 1 Requirement and is designed to resist physical attack and vandalism. Ideal for use in residential entrances, schools/universities, detention centers and healthcare facilities. Aesthetics no longer need to be compromised to achieve the highest level of security.
- Ideal for new and retrofit applications.
- Can be paired with a variety of commercial, residential, and specialty trim in a standard ANSI mortise prep.
- Passed ASTM F 1577 impact testing.
- Now recommended as the new standard for behavioral health and ligature resistant applications.
- Institutional: Paired with high security, detention grade trim, this lock ensures the prevention of unauthorized passage to secure areas, confines inmates and will delay or frustrate escape attempts.
- Residential and Commercial: This detention grade mortise lock can be paired with any architectural trim in residential or commercial settings. Achieve optimal safety without compromising style.
- Behavioral Health: Available with ADA compliant and ligature resistant trim featuring paperclip protection. Ideal for use in behavioral healthcare settings.
9101SEC Deadlock
- Deadbolt by key outside, no inside operation.
9102SEC Deadlock
(ANSI SERIES 1000-F18)
- Deadbolt by key either side.
9103SEC Deadbolt
(ANSI SERIES 1000-F16)
- Deadbolt by key outside and turn piece inside.
9104SEC Deadbolt
(ANSI SERIES 1000-F17)
- Deadbolt by turn piece inside, no outside operation.
9105SEC Deadbolt
- Deadbolt by turn piece inside and emergency key outside.
9122SEC Store Door
- Latch bolt by lever either side.
- Deadbolt by key either side.
- No emergency egress.
9124SEC Dormitory, Entrance or Storeroom
(ANSI SERIES 1000-F14)
- Latch bolt by lever either side.
- Deadbolt by key outside and turn piece inside.
- Turn of inside lever retracts latch and deadbolt simultaneously, automatically unlocking outside lever.
9125SEC Passage
(ANSI SERIES 1000-F13)
- Latch bolt by lever either side.
9134SEC Hotel or Motel
(ANSI SERIES 1000-F01)
- Latch bolt by lever and Guest or Master Key outside.
- Outside lever always rigid. Deadbolt by turn piece inside.
- Turn of inside lever retracts latch and deadbolt simultaneously.
- Auxiliary latch deadlocks latch bolt.
9139SEC Privacy Bedroom or Bathroom
(ANSI SERIES 1000-F15)
- Latch bolt by lever either side.
- Deadbolt by turn piece inside and optional emergency key outside.
- Turn of inside lever retracts latch and deadbolt simultaneously, automatically unlocking outside lever.
9142SEC Entrance
(ANSI SERIES 1000-F19)
- Latch bolt by lever either side unless outside lever is locked by Master key from inside.
- When outside lever is locked, latch bolt by key outside and lever inside.
- Auxiliary latch deadlocks latch bolt.
9143SEC Institutional Privacy
(ANSI SERIES 1000-F09)
- Latch bolt by lever either side unless outside lever is locked by thumb turn.
- Thumb turn locks or unlocks outside lever. Key locks or unlocks outside lever.
- Key retracts latch as an independent function of the thumb turn to allow retraction if thumb turn is forcibly held in locked position.
- Auxiliary latch deadlocks latch bolt. Outside lever unlocks when inside lever is turned or door closes.
9143E-SEC Institutional Privacy or Emergency Release
- Latch bolt by lever either side unless outside lever is locked by thumb turn.
- Thumb turn locks or unlocks outside lever. Emergency release locks or unlocks outside lever.
- Auxiliary latch deadlocks latch bolt.
- Outside lever unlocks when inside lever is turned or door closes.
9143i-SEC Institutional Privacy or Occupancy Indicator
- Same operation as 9143 Institutional Privacy (specify Occupancy Indicator trim separately).
9144SEC Institutional Privacy
- Latch bolt by lever either side unless outside lever is locked by thumb turn.
- Thumb turn locks or unlocks outside lever.
- Key locks or unlocks outside lever.
- Key retracts latch as an independent function of the thumb turn to allow retraction if thumb turn is forcibly held in locked position.
- Auxiliary latch deadlocks latch bolt.
- Outside lever unlocks when inside lever is turned (closing door will not unlock outside lever).
9144E-SEC Institutional Privacy or Emergency Release
- Latch bolt by lever either side unless outside lever is locked by thumb turn.
- Thumb turn locks or unlocks outside lever.
- Emergency release locks or unlocks outside lever.
- Auxiliary latch deadlocks latch bolt. Outside lever unlocks when inside lever is turned (closing door will not unlock outside handle).
9144i-SEC Institutional Privacy or Occupancy Indicator
- Same operation as 9144 Institutional Privacy (specify Occupancy Indicator Trim separately).
9144TO-SEC Time Out Lock
(ANSI SERIES 1000-F05)
- Latch retracted by lever either side unless outside thumb turn is rotated and held into position to temporarily lock inside lever.
- When thumb turn is released by user, inside lever unlocks.
- *Optional key inside retracts latch for emergency exit in case thumb turn is held locked by unauthorized person outside.
9145SEC Classroom
(ANSI SERIES 1000-F88)
- Latch bolt by key outside and lever either side unless outside lever is locked by key.
- Auxiliary latch deadlocks latch bolt.
9145D-SEC Classroom
- Deadbolt by key outside.
- Inside lever will retract deadbolt.
9145S-SEC Classroom Security
(ANSI SERIES 1000-F12)
- Latch bolt by lever either side unless outside lever is locked by key outside or inside.
- When locked, latch bolt retracted by key either side or by lever inside.
- Inside lever is always free.
- Auxiliary latch deadlocks latch bolt.
9146SEC Classroom Double Locking
- Latch bolt by key from either side.
- Key from either side locks and unlocks outside and inside* levers.
- Auxiliary latch deadlocks latch bolt.
- *Verify code compliance before specifying this function.
9153SEC Entrance or Office
(ANSI SERIES 1000-F04)
- Latch bolt by key outside and lever either side unless outside lever is locked by thumb turn or key.
- Key or thumb turn locks or unlocks outside lever.
- Auxiliary latch deadlocks latch bolt.
9156SEC Entrance or Office
(ANSI SERIES 1000-F04)
- Latch bolt by key outside and lever either side unless outside lever is locked by toggle-action stop.
- Auxiliary latch deadlocks latch bolt.
9158SEC Institution or Asylum
(ANSI SERIES 1000-F30)
- Latch by key either side.
- Inside* and outside handle is always RIGID.
- Auxiliary latch deadlocks latch bolt.
- *Verify code compliance before specifying this function.
9159SEC Store Room or Closet
(ANSI SERIES 1000-F07)
- Latch by lever inside and key outside.
- Outside lever always rigid.
- Auxiliary latch deadlocks latch bolt.
9160SEC Asylum with Deadbolt
- Latch by key either side.
- Deadbolt by key either side (key projects deadbolt and retracts latch bolt and deadbolt).
- Inside* and outside lever always rigid.
- Auxiliary latch deadlocks latch bolt.
- *Verify code compliance before using this function.
9167SEC Entrance or Apartment Lock
(ANSI SERIES 1000-F20)
- Latch bolt by key outside and lever either side, unless outside lever is locked by toggle-action stop.
- Deadbolt by key outside and turn piece inside.
- Turning inside lever retracts latch and deadbolt simultaneously.
- Outside lever remains locked until manually unlocked by toggle.
- Auxiliary latch deadlocks latch bolt and prevents manipulation of locked toggle-action stop.
9169SEC Entrance or Apartment Lock
- Latch bolt by key outside and lever either side, unless outside lever is locked by toggle-action stop.
- Deadbolt by key outside and turn piece inside.
- Turning inside lever retracts latch and deadbolt simultaneously.
- Outside lever remains unlocked until manually locked by toggle or projection of deadbolt.
- Auxiliary latch deadlocks latch bolt and prevents manipulation of locked toggle-action stop.
Click on a swatch below to get a closer look
-
CVB
Cerakote Vortex Bronze
-
CBG
Cerakote Black Gloss
-
Cerakote White Gloss
CWG
-
CWM
Cerakote White Matte
-
CBM
Cerakote Black Matte
-
US4
Satin Brass
-
US4NL
Satin Brass + No Lacquer
-
US32D
Satin Stainless Steel
-
US26D
Satin Chrome
-
US3
Polished Brass
-
US3NL
Polished Brass + No Lacquer
-
US26
Polished Chrome
-
US32
Bright Stainless Steel
-
US9
Polished Bronze
-
US10
Satin Bronze
-
US10B
Oil Rubbed Bronze
-
US14
Polished Nickel
-
US15
Satin Nickel
-
US19
Oxidized Black + Lacquer
-
US19LL
Oxidized Black Less Lines + Lacquer
-
BN
Burnished Nickel
-
BB
Burnished Brass
-
TN
Tarnished Nickel
-
TB
Tarnished Brass
-
DURO
Duronotic
-
ESN
Electroless Nickel
-
US15A
Antique Nickel
-
US5
Satin Brass + Black
-
Cerakote
Protective Ceramic Coating
US26D
Satin Chrome
How to Specify
Function. Backset. Trim. Finish. Hand. Door Thickness.
Examples
-
High Security Institutional Privacy Lock | Accurate Trim
E.g.: 9143SEC. 234. 19L/1R. US10B. RH. 134 -
High Security Institutional Privacy with Occupancy Indicator | Accurate Trim
E.g.: 9143SEC-i. 212. 18L/1R. US5. RH. 134 -
High Security Entrance or Apartment Lock | Accurate Trim
E.g.: 9167SEC. 234. 19L/1E. BB. LH. 134
Notes
- Furnished standard with security strike (no additional charge).
- A reinforced latching strike plate fortifies the opening to prevent kick-in type burglaries.
- A solid machined steel plate is secured by four individual three-inch steel screws that reach into the opening’s studded framing.
- Normal strikes typically fasten to the door finish trim only when combined with the 9100SEC, a reinforced strike plate adds solid protection to the most vulnerable part of the door opening.
